Description
DCS Batteries are the ideal drop in replacement & upgrade from AGM, Gel or other lead acid batteries for any application. DCS gives you the ability to upgrade your current batteries to lithium ion technology that can deliver a minimum of 2500 cycles and has tremendous advantages in weight, performance, reliability and service life compared to that of traditional lead acid batteries.
Backed by a 5 year return to base warranty.
FREE delivery to all major cities in Australia.
-------------------------------------------------------------------------------
All DCS batteries now feature our comprehensive Bluetooth System available on both Android and Apple operating systems shows a lot of cool things.
– Cell status showing real time cell balancing operation
– BMS MOSFET temperature ( great info when your winching or running a large inverting load or your trolling motor to know how hard your pushing the electronics ).
– SOC% estimate (using impedance tracking – the App learns the SOC after the first 10 cycles)
– Battery pack voltage and cycle count
– Amp meter – showing charge and discharge current
– Connectivity distance up to 10m
– Now there is no need to install battery monitors or shunts in boats, campers or vehicles. You have all the info you need at your finger tip.
– The SOC estimate is accurate on single batteries, the more batteries that are expanded in parallel the less accurate the SOC becomes.
– This free application provides the perfect tell-tale about the battery packs state of health as it ages
– Assists installers & integrators to quickly diagnose any system issues
DCS HIGH PERFORMANCE 2C CHARGE & DISCHARGE CURVES
| Specifications: | – |
|---|---|
| Nominal Voltage | 12.8V |
| Nominal Capacity (1Hr) | 100Ah |
| Case Dimensions (L x W x H) | 690mm x 50mm x 300mm |
| Weight | 13.0 Kg |
| Cycling voltage | 11.5 ~ 14.6V |
| Charge voltage | 14.0 ~ 14.6V |
| Float Voltage | 13.5 ~ 13.7V |
| Maximum Charge Current | 100A |
| Recommended Charge Current | ≤70A |
| Maximum Discharge Current | ≤200A |
| BMS (built in) | Automatic cell balancing, over discharge/charge |
| Cell Chemistry | DCS 3.2V 5.0 – 7.2Ah Cylindrical (LifePO4) |
| Cycle Performance | 2500 Cycles @ 100% DOD |
| LCA | 1000 |
| Ingress Protection | IP54 |
| Case | Metal With White Finish |
| Operating temp Range | -30 to +80 degrees C |
| Terminals | Twin 120A Anderson Plugs |
| Parallel Connections Only | YES |
| Series Connections | No |
| Warranty | 5 years |
DOWNLOAD APP (DCS LFP)
DCS Bluetooth Technology powered by DCS LFP, this APP is only for DCS LFP batteries which is based on BLE 4.0 technology. Every DCS battery pack comes standard with our detailed battery monitoring via Bluetooth.
This App provides comprehensive monitoring for DCS LFP batteries, including:
- SOC%
- Time Remaining
- Battery pack voltage, Power & Current
- Battery Management MOSFET temperature
- Individual Cell Status with balancing indicators.
- Connectivity distance up to 10 meters.
- Every DCS battery pack comes standard with our detailed battery monitoring via Bluetooth
Learn More About the DCS LFP APP
