Description
The REMCO XTRA series with SmartSense has an ingenious way of working with Smart Alternators. Simply plug your start battery connection directly into the DC input Blue Anderson Plug and charging is optimised to work straight out of the box. For those who want to configure an ignition trigger input, or more sophisticated charging set-ups, the battery has these options available on the two variable switch settings on the battery.
Constructed using hard case metal lithium iron phosphate cells, the battery has an inbuilt Battery Management System (BMS) designed and developed in Australia. Providing up to 120A of continuous discharge and accepting up to 120A of charge, the battery is ready to power your high amperage appliances. The strong aluminium outer enclosure delivers a safe, lightweight and powerful unit which is the perfect building block for next generation battery systems.
At just under 13 kg, the unique slimline shape makes it the perfect battery for installations where space is a premium. Slide it behind a seat, under a tray, or against the wall in a custom canopy.
RM12-110LFPXSLSS
- 5 year warranty
- Chemistry LiFePO4
- Nominal Voltage 12.0 V
- Nominal Capacity 110 Ah
- Nominal Energy 1.3 kWh
- Input Charge Voltage 13.8 V - 14.6 V 14.0 V recommended
- 100% SoC Voltage 13.8 V
- Low Voltage cut-off 10.5 V approx
- Charge Current 120 A max
- Discharge Current 120 A max cont.
- 240 A surge
- Weight 12.9 kg
- Packaged Weight 13.3 kg
- Life at 80% DoD 2000 cycles
- Life at 50% DoD 5000 cycles
- Parallel Capable Yes (Unlimited)
- Series Capable No
- Size L 636 mm D 256 mm H 50 mm
FEATURES
✓ Strong, compact aluminium enclosure
✓ Internal BMS
✓ Over/Under voltage protection
✓ Overcurrent protection
✓ Short circuit protection
✓ Parallel connect capable
✓ Integrated DC-DC Charger with SmartStart: 20 A, 10 V-16 V
✓ 1x Grey Anderson (Max 120A)
✓ 1x Blue Anderson (DC-DC Input)
✓ 1x DC-DC Ignition Trigger Socket
✓ Designed and fully assembled in Australia
Includes mounting brackets
